DC 1′ x DCONMS 1′ x APMX 1-1/2′ x OAL 7′
3 Flute End Mill for Finishing, Variable Pitch, Center cutting, 45° helix angle, Reduced Neck. For Aluminum and Non-Ferrous alloys
| Cutting Diameter (DC) | 1″ | Grade | H5005 Exxtral Carbon (DLC) |
| Connection Diameter Machine Side (DCONMS) | 1″ | Neck Diameter (DN) | 0.97″ |
| Depth of Cut Maximum (APMX) | 1-1/2″ | Tool Type | Solid Carbide Endmill |
| Overall Length (OAL) | 7″ | Maximum Feed per Tooth (fz(max)) | 0.015 ″/tooth |
| Flute Count (NOF) | 3 | Minimum Feed per Tooth (fz(min)) | 0.005 ″/tooth |
| Shank Type | Round | Shank Standard | h6 |
| End Shape | Corner Radius | Body Material | Carbide |
| Usable Length (LU) | 5″ | Decimal Equivalent | 1″ |
| Applicable Material | | Aluminum / Non-Ferrous Materials | | Measurement Type | Inch |
| Application | | Finish | HEM | Roughing | Semi Finish | Shouldering | Slotting | | Series/List # | 360 |
| Corner Radius (RE) | 0.06″ | Unit | I |
Product Features
| Family Description | 3 Flute End Mill for Finishing, Variable Pitch, Center cutting, 45° helix angle, Reduced Neck. For Aluminum and Non-Ferrous alloys | FamilyName | 360 - Reduced Neck Square & Radius Variable |
| COO | Usa | BrandName | Precision Cutting Tools |
| ItemRemark | click here for cutting data |
Shipping Info
Weight per item
0.0000
Name
Square & Corner Radius End Mills
FamilyName
360 - Reduced Neck Square & Radius Variable
BrandName
Precision Cutting Tools
